Copper Foils For Transformer Windings

copper strip for transformer windings

Copper 99.9%
high conductivity
width tolerance is ± 0.2mm
The thickness control can be controlled below ± 5 microns
Used for distribution system, low voltage transformer windings.

Copper Foils For Transformer Winding is widely sold in the world with high performance, also called transformer Copper Coils. The commonly used copper grades are ETP Grade (Electrolytic Tough Pitch), C11000, UNS C10200 TU1, temper O or H state.

Copper Foils For Transformer Winding Technical parameters

NameCopper Foils
GradeCu-ETP/C-11000/E -Cu58
TemperSoft(O),Hard(H)
DimensionThickness: 0.1-4.0mm; width: 20-1500mm
StandardASTM,EN 13599,GB-T 18813-2002
Packing: In coil, Inner Diameter: 300mm, 400mm, 500mm, etc.IEC, NEMA, GB, JIS

Transformer Copper Foils Features
1. Super Thin, No Burrs and no scratch
2. Totally annealed
3. High strength
4. Above 99.80% IACS high electric conductivity
5. Excellent side camber 2mm/meter

The manufacturing process of transformer copper strips
it includes continuous up-casting, continuously extruded, milling face, rolling, welding, milling face, high annealing, rolling, low-temperature annealing, Cleaning and Passivation, aligning, cutting, chamfering, the main method by welding, the width for improving copper strips, meets the width requirement of transformer copper strips.

The standard of Copper Coils

INDUSTRYUSAITALYCHINAEURONORMJAPANESE
STANDARDASTM B5, B152UNI 5649GB/TEN 1652DIN 1976JIS
C1100C11000Cu-ETPT2CW004AE-Cu 58C1100
